Broadcast Stream Analyzer
Overview
The Broadcast Stream Analyzer is DigiCAP’s dedicated tool for in-depth analysis and monitoring of ATSC 3.0 and TV 3.0 streams. It offers full STLTP decoding, advanced signaling analysis, and real-time video decoding to ensure standards-compliant transmission. With intuitive visualizations and smart error detection, it turns complex stream data into clear, actionable insights. Engineers and broadcasters like TV Globo rely on it for fast troubleshooting and consistent quality across Brazil’s TV 3.0 rollout.
Key Features
Broadcast Stream Analyzer gives deep, real-time insights to keep your ATSC 3.0 / TV 3.0 streams compliant, stable, and error-free with key features like:
- Comprehensive STLTP analysis
- Real-time video decoding & visualization
- Error & anomaly detection
- Visual confirmation
- Rapid troubleshooting
Why Broadcast Stream Analyzer
Conventional monitoring tools don’t provide enough visibility into STLTP or next-gen codec workflows. The Broadcast Stream Analyzer solves such issues by delivering
- End-to-end verification
- Faster problem resolution
- Enhanced quality assurance
- Confidence in rollout
- Optional integration with Enterprise Monitoring for centralized oversight
Specifications
Standards Support
ATSC 3.0 STLTP (LLS, SLTP payloads), IP/service analysis
Codec Support
VVC+LCEVC, UHD 4K/8K decoding
Error Detection
Latency, frame drops, color errors, and compression artifacts.
UI
Web-based interface with video visualization and error highlighting.
Deployment
Cloud-hosted subscription service on NexCaster platform, fully managed by DigiCAP with continuous updates included.
Architecture
Core Platform Capabilities
- Input layer : Ingests ATSC 3.0 STLTP streams and extracts LLS, SLTP payloads, and IP/service data
- Analysis engine : Performs signaling decoding, anomaly detection, and error analysis.
- Video decoding layer : Real-time decoding of UHD streams with codec error visualization.
- UI/dashboard : Intuitive interface with stream details, decoded video, and highlighted errors.
- Inputs : STLTP streams, IP-based broadcast transport.
- Decoded outputs : Signaling data tables, IP/service info, video visualization.
- Reports : Error logs, anomaly reports, visual snapshots.
- Local deployment : Ensures sensitive broadcast stream data stays within the broadcaster’s network.
